Description
Precoated Flow Rate (Filtering Capacity) |
3,500 gph |
Open Pumping Capacity |
5,400 gph |
Filtration Surface Area |
32 ft? |
Number of Filter Media |
48 |
Filter Media Diameter |
12 “ |
Sludge Holding Capacity |
806 in? |
Approximate Length |
43 “ |
Approximate Width |
20 “ |
Approximate Height |
53 “ |
Approximate (Crated) Weight |
550 lbs |
Hose Connection Suction |
2 in Inlet |
Hose Connection Discharge |
1-1/2 in Outlet |
Hose Length |
20 ft |
Motor (TEFC) |
2 hp |
Pump Options |
PPQ – Magnetic Self-Priming Pump – Standard
PPS – Mechanical Seal CRS-40-PP – No Extra Charge |
Slurry Tank Option |
NO SLURRY TANK – Standard
WITH SLURRY TANK – Adder |
