*(Note: LSD Denotes Dual Chamber Filtration System)
Description
Precoated Flow Rate (Filtering Capacity) |
30,000 gph |
Open Pumping Capacity |
14,400 gph |
Filtration Surface Area |
124 ft? |
Number of Filter Media |
70 |
Filter Media Diameter |
19 “ |
Sludge Holding Capacity |
5.94 ft? |
Length |
90 “ |
Width |
55 “ |
Height |
55 “ |
Hose Connections Suction Discharge |
2 “2-1/2 “ |
Hose Length (Suction and Discharge) |
10 ft (Two of Each) |
| Motor1 | 5 HP TEFC (Two Motors) |
Pump Options |
CRS Pump with Mechanical Seal – Standard
PPM – Magnetic End Suction Pump- Adder PPQ – Magnetic Self-Priming Pump – Adder |
Slurry Tank Option |
WITH SLURRY TANK – Standard |
Weight |
1900 lbs |
