CECO Mefiag brand steel rubber-lined High Capacity Electroplating Filter Systems feature horizontal disc technology and capacities from 3,200 to 4,400 gph for Single Chamber.
Designed for the filtration of nickel, copper and zinc electrolytes.
- Operating temperature to 190 ?F (90 ?C).
- Depending on the type of process, single chamber systems are designed for plating tanks ranging from 600 to 2,500 gallons.
- Can be supplied with high profile (for zinc) or low profile (for nickel and copper)
Description
Precoated Flow Rate (Filtering Capacity) |
9,000 gph |
Open Pumping Capacity |
10,200 gph |
Filtration Surface Area |
62 ft? |
Number of Filter Media |
35 |
Filter Media Diameter |
19 “ |
Sludge Holding Capacity |
2.97 ft? |
Length |
53 “ |
Width |
39 “ |
Height |
53 “ |
Hose Connections Suction Discharge |
2 “2-1/2 “ |
Hose Length (Suction and Discharge) |
10 ft |
| Motor1 | 5 HP TEFC |
Pump Options |
CRS Pump with Mechanical Seal – Standard
PPM – Magnetic End Suction Pump- Adder PPQ – Magnetic Self-Priming Pump – Adder |
Slurry Tank Option |
NO SLURRY TANK – Standard
WITH SLURRY TANK – Adder |
