Description
Precoated Flow Rate (Filtering Capacity) |
4,500 gph |
Open Pumping Capacity |
7,200 gph |
Filtration Surface Area |
44 ft? |
Number of Filter Media |
44 |
Filter Media Diameter |
14 “ |
Sludge Holding Capacity |
.92 ft? |
Length |
41 “ |
Width |
30 “ |
Height |
50 “ |
System Connections Suction |
2″ NPT (Female) |
System Connections Discharge |
1.5″ NPT (Female) |
| Motor (TEFC)1 | 3 hp |
Pump Options |
CRS Pump with Mechanical Seal – Standard
PPM – Magnetic End Suction Pump- Adder PPQ – Magnetic Self-Priming Pump – Adder |
Slurry Tank Option |
NO SLURRY TANK – Standard
WITH SLURRY TANK – Adder |
Weight |
720 lbs |
